SMT Pick And Place Machine Vision SMT460,0402,0805,0603,5050
Desktop Pick And Place Machine
| CHM-T530P4 Specifications |
| Dimensions | 1060mm(L)×780mm(W)×600mm(H) |
| Weight | 115kg |
| Power Supply | AC220V (50Hz, single phase) /AC110V (60Hz, single phase); 400W |
| Air Supply | 0.5MPa~0.7MPa |
| Vacuum Generation | Built-in vacuum pump |
| Mounting Head Quantity | 4 |
| Mounting Speed | 8000cph(optimal without vision detection); 5500cph (optimal with vision detection) |
| Control Accuracy | 0.015mm |
| Component Type | 0402/0603～5050/SOT/SOP/QFP/QFN/BGA, etc. (resistor/capacitor/diode/triode/LED/IC, etc.) |
| PCB Thickness | 0.6mm~3.5mm |
| PCB Size | 10mm(L)×10mm(W)～400mm(L)×330mm(W) |
| PCB Conveying | Manual operation |
| Nozzle Change | Manual operation |
| Control System | Built-in computer (embedded Linux operating system), 7-inch touch screen |
| Drive System | X&Y-axis driven by stepping motors in the way of closed-loop control; Z-axis capable of reset detection;all motors adopting flexible S-curve acceleration and deceleration |
| Transmission System | Synchronous belt + linear guide |
| Feeding System | 30 Yamaha standard pneumatic feeder stacks (also suitable for Yamaha electric feeder, IC tray, and stick feeder), 11 preset general IC stacks, work surface custom IC trays supported |
| Vision System | Up-looking camera for component automatic calibration (component size applicable: 22mm×22mm); down-looking camera for PCB calibration via Mark Point and component positioning |
CHM-T530P4 pick and place machine It is widely used in intelligent appliance , LED , power supply, automotive electronics, main controller and etc.
Charmhigh already owns 24 property rights, including 22 national patents and two software copyrights, and has passed ISO quality management system certification, EU CE certification, ROHS certification, and US FCC, SGS and other international certifications.
We support one year warranty. We will regularly update the software for customers. If there is any doubt in the process of operating the machine,please feel free contact us. We will help you in time.All the spare parts will be provided free of charge for you within the warranty period.
FAQ:
Q:This is the first time I use this kind of machine, is it easy to operate?
A:Yes. There are English manual and guide video that show you how to use machine.If there is any doubt in the process of operating the machine, please feel free contact us.We provide overseas distance learning services
Q:Can we customize the machine?
A:Of course. Our machines can custom made provide the number of stacks and the maximum size of PCB boards
Q:How about the warranty?
A:We support one year warranty. We will help you in time. All the spare parts will be provided free of charge for you within the warranty period.
|
|
